● Quiescent Current: 17μA/Amplifier (TYP)

● Low Offset Voltage: 10μV (TYP), 50μV (MAX)

● Low 0.1Hz to 10Hz Noise: 1μVP-P

● Gain-Bandwidth Product: 200kHz

● Unity-Gain Stable

● Integrated RFI Filter

● Single or Dual Supply Operation

● Supply Voltage Range: 1.8V to 5.5V

● Rail-to-Rail Input and Output

● -40℃ to +125℃ Operating Temperature Range

The single SGM8953-1 and dual SGM8953-2 CMOS operational amplifiers provide very low offset voltage and zero-drift over time and temperature.

The miniature, high precision, low quiescent current amplifiers offer high-impedance inputs that have a wide input common mode range of 100mV beyond the rails and rail-to-rail output that swings within 5.5mV of the rails. Single or dual supplies as low as 1.8V (±0.9V) and up to 5.5V (±2.75V) may be used. They are optimized for low voltage, single or dual supply operation.

The SGM8953-1/2 offer excellent CMRR without the crossover associated with traditional complementary input stages. This design results in superior performance for driving analog-to-digital converters (ADCs) without degradation of differential linearity.
