• High Efficiency, 1.5MHz, Synchronous

  Buck Charger

  95% Charge Efficiency at 1A from 5V Input

  91.4% Charge Efficiency at 2A from 9V Input

  Optimized for USB Voltage Input (5V)

  Selectable PFM Mode for Light Load Efficiency

• USB On-The-Go (OTG) Support (Boost Mode)

  Boost Converter with up to 2A Output

  Boost Efficiency of 93.5% at 0.5A and 94.3% at 1A

  Accurate Hiccup Mode Over-Current Protection

  Output Short Circuit Protection

  Selectable PFM Mode for Light Load Operations

• Single Input for USB or High Voltage Adapters

  3.9V to 13.5V Operating Input Voltage Range

  22V Absolute Maximum Input Voltage Rating

  Programmable Input Current Limit and

  DynamicPower Management (IINDPM,

  100mA to 3.1A with100mA Resolution & 3.8A)

  to Support USB 2.0 andUSB 3.0 Standards and

  High Voltage Adaptors

  Maximum Power Tracking by Programmable

  InputVoltage Limit (VINDPM) with Selectable Offset

  VINDPM Tracking of Battery Voltage

  Auto Detect USB BC1.2, SDP, CDP, DCP

  andNon-Standard Adaptors

• High Battery Discharge Efficiency

  with 19mΩ Switch

• Narrow Voltage DC (NVDC) Power

  Path Management

  Instant-On with No or Highly Depleted Battery

  Ideal Diode Operation in Battery

  Supplement Mode

• Ship Mode, Wake-Up and Full System

  Reset Capabilityby Battery FET Control

• Flexible Autonomous and I2C Operation

  Modes forOptimal System Performance

• Fully Integrated Switches, Current Sense

  andCompensation

• External Direct Charging Path Enable Output

• 9μA Ship Mode Low Battery Leakage Current

• High Accuracy

  ±0.6% Charge Voltage Regulation (8mV/Step)

  ±5% Charge Current Regulation at 2A

  ±10% Input Current Regulation at 0.9A

• Safety

  Battery Temperature Sensing

   (Charge/Boost Modes)

  Thermal Regulation and Thermal Shutdown

  Input Under-Voltage Lockout (UVLO)

  Input Over-Voltage (ACOV) Protection
