SGM8581XN5G.pdf• Low Offset Voltage: 100μV (MAX)
• Rail-to-Rail Input and Output Swings
• 2.5V to 5.5V Single-Supply Operation
• Voltage Gain: 145dB (TYP) at 5V
• PSRR: 120dB (TYP)
• CMRR: 90dB (TYP)
• Ultra Low Input Bias Current: 15pA
• Low Supply Current: 445μA at 5V
• Overload Recovery Time: 70μs (at VS = 5V)
• No External Capacitors Required
• -40℃ to +125℃ Operating Temperature Range
• Available in Green SOT-23-5, SOIC-8 and MSOP-8
Packages
• CMOS Rail-To-Rail Input/Output
• Input Bias Current: 2.5pA
• Low Supply Current: 600μA/Channel
• Ultra-Low Power Shutdown Mode:
IDD(SHDN): 350nA/ch at 3V
IDD(SHDN): 1000nA/ch at 5V
• Gain-Bandwidth Product: 2.8MHz
• High Output Drive Capability:
±10mA at 180mV
±35mA at 500mV
• Input Offset Voltage: 250μV (typ)
• Supply Voltage Range: 2.7V to 6V
• Ultra-Small Packaging
SOT23-5 or -6 (TLV2470/1)
MSOP-8 or -10 (TLV2472/3)
