SGM8634CXTS14G.pdf• Rail-to-Rail Input and Output
• Input Offset Voltage: 3.5mV (MAX)
• High Gain-Bandwidth Product: 6MHz
• High Slew Rate: 3.7V/μs
• Settling Time to 0.1% with 2V Step: 2.1μs
• Overload Recovery Time: 0.9μs
• Low Noise: 12nV/ Hz
• Supply Voltage Range: 2.5V to 5.5V
• Input Voltage Range: -0.1V to 5.6V with VS = 5.5V
• Low Supply Current: 470μA/Amplifier (TYP)
• -40℃ to +125℃ Operating Temperature Range
• Available in Green TSSOP-14 and SOIC-14 Packages
• Rail-to-Rail Output Swing
• Gain Bandwidth Product . . . 6.4 MHz
• ±80 mA Output Drive Capability
• Supply Current . . . 500 μA/channel
• Input Offset Voltage . . . 100 μV
• Input Noise Voltage . . . 11 nV/√Hz
• Slew Rate . . . 1.6 V/μs
• Micropower Shutdown Mode
(TLV2460/3/5) . . . 0.3 μA/Channel
• Universal Operational Amplifier EVM
• Available in Q-Temp Automotive
HighRel Automotive Applications
Configuration Control/Print Support
Qualification to Automotive Standards
