• Junction passivation optimized design passivated anisotropic

   rectifier technology

• TJ = 175 °C capability suitable for high reliability and

   automotive requirement

• Available in uni-directional polarity only

• Low leakage current

• Low forward voltage drop

• High surge capability

• Meets ISO7637-2 surge specification (varied by test condition)

• Meets MSL level 1, per J-STD-020, LF maximum peak of 245 °C

• AEC-Q101 qualified

Use in sensitive electronics protection against voltage transients induced by inductive load switching and lighting, especially for automotive load dump protection application.
