LM2904XTS8G/TR.pdf• Wide Supply Ranges
Single Supply: 3V to 32V
Dual Supplies: ±1.5V to ±16V
• Low Quiescent Current: 440μA (TYP)
• Gain-Bandwidth Product: 1.1MHz
• Input Common Mode Voltage Range IncludesGround,
Allowing Direct Sensing Near Ground
• Low Input Offset Voltage: 5.8mV (MAX)
• Low Input Offset Current: 10pA (TYP)
• Low Input Bias Current: 10pA (TYP)
• Differential Input Voltage Range Equal to
Maximum-Rated Supply Voltage: 32V
• Open-Loop Differential Voltage Gain: 111dB (TYP)
• Internal Frequency Compensation
• -40℃ to +125℃ Operating Temperature Range
• Available in Green SOIC-8, MSOP-8 and TSSOP-8Packages
• Trimmed Offset Voltage:
TLC277 . . . 500 μV Max at 25°C,
VDD = 5 V
• Input Offset Voltage Drift . . . Typically
0.1 μV/Month, Including the First 30 Days
• Wide Range of Supply Voltages Over
Specified Temperature Range:
0°C to 70°C . . . 3 V to 16 V
–40°C to 85°C . . . 4 V to 16 V
–55°C to 125°C . . . 4 V to 16 V
• Single-Supply Operation
• Common-Mode Input Voltage Range
Extends Below the Negative Rail (C-Suffix,
I-Suffix types)
• Low Noise . . . Typically 25 nV/√Hz at
f = 1 kHz
• Output Voltage Range Includes Negative
Rail
• High Input impedance . . . 1012 Ω Typ
• ESD-Protection Circuitry
• Small-Outline Package Option Also
Available in Tape and Reel
• Designed-In Latch-Up Immunity
